The COMI Landscape lighting's D1CA-series LED wall light & Stair light is designed for wall or step integration and offers various design possibilities in architectural illumination.
Rectangle front cover
110-120V or 220-240Vac 50/60Hz input.
Light source: 36pcs or 48pcs 20-25LM 2835SMD LED.
Lighting fixture luminous flux:680LM for 8W and 960 for 12W
CRI(Ra)>80 (for 2200-6500K only).
Color: 2200-6500K.
Honey comb-type clear tempered glass light window.
Optional Lamp body color: Mat Light grey, Mat black, Mat white
Easy wall recessed install by mounting sleeve.
ABS mounting sleeve(also named Pre-buried box) included.
IP classification: IP65 (for outdoor use).
2 Years warranty.
| Housing | 12 Die-casting grey powder coated aluminum.T=60-80μm. Adhesion of ISO class 1/ASTM class 4B |
|---|---|
| Front Cover | 12 Die-casting grey powder coated aluminum.T=60-80μm. Adhesion of ISO class 1/ASTM class 4B |
| Gasket | Molding shaped silicone seal |
| LED | 48pcs 2835 SMD LED, 20-25LM/LED |
| Driver | Tridonic Constant voltage output |
| Operating Temperature | -20℃~40℃ |
| Item Number | Light Source | CRI(Ra) (White color) | Lens | Selected Lens Degree (Θ1/2) | Input Voltage (V) | Typical Operating Current(mA) | Typical Power Consumption(W) | Typical Luminance(lm) | IK Rated |
|---|---|---|---|---|---|---|---|---|---|
| D1CA3607 |
36× 2835 SMD
LED(20-25LM/LED) (Single Color) |
Ra>80 | / | 120° | 120/240 |
120V=72
240V=36 |
120V=8
240V=8 |
Cool white=680
Warm white=577 |
10 |
| D1CA4807 |
36× 2835 SMD
LED(20-25LM/LED) (Single Color) |
Ra>80 | / | 120° | 120/240 |
120V=72
240V=36 |
120V=8
240V=8 |
Cool white=680
Warm white=577 |
10 |
1. Color: Mono (2000K,2400K,2700K, 3000K, 4000K, 6000K, Red,Green, Blue and etc.)
2. Specifications are subjected to change without notice.
